Double Shafts Clay Mixer Kneader 100L Sigma Arm Kneading Mixer Vacuum Kneader
  • Double Shafts Clay Mixer Kneader 100L Sigma Arm Kneading Mixer Vacuum Kneader
  • Double Shafts Clay Mixer Kneader 100L Sigma Arm Kneading Mixer Vacuum Kneader
  • Double Shafts Clay Mixer Kneader 100L Sigma Arm Kneading Mixer Vacuum Kneader
  • Double Shafts Clay Mixer Kneader 100L Sigma Arm Kneading Mixer Vacuum Kneader
  • Double Shafts Clay Mixer Kneader 100L Sigma Arm Kneading Mixer Vacuum Kneader
  • Double Shafts Clay Mixer Kneader 100L Sigma Arm Kneading Mixer Vacuum Kneader
Double Shafts Clay Mixer Kneader 100L Sigma Arm Kneading Mixer Vacuum Kneader

Double Shafts Clay Mixer Kneader 100L Sigma Arm Kneading Mixer Vacuum Kneader

Place of Origin Shandong, China
Brand Name SANWEI
Certification CE ISO
Product Details
Mixer Type:
Sigma / Z Blade
Barrel Volume (L):
500 L
Material Processed:
Chemicals
Max. Loading Volume (L):
300 L
Range Of Spindle Speed(r.p.m):
21 - 37 R.p.m
Max. Loading Capacity:
300kg
Weight (KG):
4000 KG
Material:
SUS304, SUS304L, SUS316, SUS316L, SS304 ; SS316 ; Carbon Steel
Condition:
New
Product Type:
High Viscosity Material
Application:
Viscous Fluid
Additional Capabilities:
Heating
Voltage:
Customer Required
Dimension(L*W*H):
Depend On The Model
Power (kW):
22 KW
Warranty:
1 Year
Key Selling Points:
Long Service Life
Applicable Industries:
Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Advertising Company, OTHER
Showroom Location:
None
Marketing Type:
Ordinary Product
Machinery Test Report:
Provided
Video Outgoing-inspection:
Provided
Warranty Of Core Components:
1 Year
Core Components:
Motor, Reducer
Product Name:
Vacuum Kneader
Model:
5~2000L
Machine Type:
Double Shafts Clay Mixer Kneader
Keyword:
Sigma Arm Kneading Mixer
Stirrer Type:
Sigma / Z Arm Blade
Structure:
Single Layer, With Jacket
Type:
Ordinary Type, Vacuum Type
Open The Cover:
Hydraulic Opening
Discharge:
Hydraulic Tilt, Screw Extruding
After-sales Service Provided:
Online Support, Video Technical Support, Free Spare Parts, Field Installation, Commissioning And Training, Field Maintenance And Repair Service
After Warranty Service:
Video Technical Support, Online Support, Spare Parts, Field Maintenance And Repair Service
Local Service Location:
None
Port:
QINGDAO
High Light:

double shafts clay mixer kneader

,

100l clay mixer kneader

,

vacuum kneader kneading mixer

Payment & Shipping Terms
Price
$1,250.00 - $9,800.00/sets
Packaging Details
Suitable Delivery And Protect The Machine
Supply Ability
100 Set/Sets per Quarter
Product Description
Double Shafts Clay Mixer Kneader 100L Sigma Arm Kneading Mixer Vacuum Kneader 0
100l 300l 500l sigma arm kneading mixer double shafts clay mixer kneader vacuum kneader
Sigma mixer is widely used in high viscosity product, such as sealant, silicon rubber, glue, adhesive, dye, BMC, CMC etc.
Main Features:
1. Material: SS304 , SS316L, carbon steel
2. Structure: single layer, double layer with jacket to heating or cooling
3. Heating method: electric heating, circulation oil heating, steam heating
4. Type: normal type , vacuum type.
5. Discharge way: hydraulic tilt , screw extruding , bottom valve.
6. We support customization.
Double Shafts Clay Mixer Kneader 100L Sigma Arm Kneading Mixer Vacuum Kneader 2
Double Shafts Clay Mixer Kneader 100L Sigma Arm Kneading Mixer Vacuum Kneader 3
Double Shafts Clay Mixer Kneader 100L Sigma Arm Kneading Mixer Vacuum Kneader 4
Double Shafts Clay Mixer Kneader 100L Sigma Arm Kneading Mixer Vacuum Kneader 5
Double Shafts Clay Mixer Kneader 100L Sigma Arm Kneading Mixer Vacuum Kneader 6
Double Shafts Clay Mixer Kneader 100L Sigma Arm Kneading Mixer Vacuum Kneader 7
Double Shafts Clay Mixer Kneader 100L Sigma Arm Kneading Mixer Vacuum Kneader 8
Double Shafts Clay Mixer Kneader 100L Sigma Arm Kneading Mixer Vacuum Kneader 9
Double Shafts Clay Mixer Kneader 100L Sigma Arm Kneading Mixer Vacuum Kneader 10
Double Shafts Clay Mixer Kneader 100L Sigma Arm Kneading Mixer Vacuum Kneader 11
Model
Main Motor Power
Blade Rotate Speed (optional inverter regulation speed)
Heating Power (optional)
Discharge Method (optional)
Vacuum Pump Power (optional vacuum)
5L
0.75KW
33/23 rpm
1KW
manual tilt
2.2KW
10L
1.1KW
33/23 rpm
2KW
manual tilt
2.2KW
100L
4KW
35/22 rpm
12KW
hydraulic tilt
screw extruding
bottom valve
2.2KW
200L
7.5KW
35/22 rpm
18KW
hydraulic tilt
screw extruding
bottom valve
2.2KW
300L
15KW
37/21 rpm
24KW
hydraulic tilt
screw extruding
bottom valve
2.2KW
500L
22KW
35/25 rpm
36KW
hydraulic tilt
screw extruding
bottom valve
2.2KW
1000L
37KW
30/16 rpm
36KW
hydraulic tilt
screw extruding
bottom valve
4KW
1500L
45KW
30/16 rpm
45KW
hydraulic tilt
screw extruding
bottom valve
5.5KW
2000L
55KW
30/16 rpm
45KW
hydraulic tilt
screw extruding
bottom valve
5.5KW
Material: SS304, SS316L, Carbon Steel
Type: single layer or with jacket to heating or cooling
Open the cover: by manual or hydraulic opening
Discharge: hydraulic tilt, screw extruding, bottom valve
Vacuum can be selected





The above data is just for your reference, we support customization.





Double Shafts Clay Mixer Kneader 100L Sigma Arm Kneading Mixer Vacuum Kneader 12
Silicone sealant production line, we have all these machines. If you are interested in any items, please feel free to contact us, thanks.
